GIGABYTE MB X870E AORUS ELITE WIFI7 (AM5, 4x DDR5 256GB, 1x PCI-E 5.0 x16x16, 1x PCI-E 4.0 x16x4, 1x PCI-E 3.0 x16x2, 3x M.2 PCI

GIGABYTE MB X870E AORUS ELITE WIFI7 (AM5, 4x DDR5 256GB, 1x PCI-E 5.0 x16x16, 1x PCI-E 4.0 x16x4, 1x PCI-E 3.0 x16x2, 3x M.2 PCIe 5.0 & 1x M.2 PCIe 4, 4x SATA, 2x USB4 Type-C, 6x USB 3.2, 3x USB 2.0, 1x HDMI, Realtek Wi-Fi 7, 2.5GbE LAN, ATX)

€349.90

Tax included

Sold Out

Reference: X870E A ELITE WIFI7

Category: Motherboards

Description
Product Details

Technical specifications

Chipset	AMD X870E
Supports Central Processor Unit	AMD Ryzen 7000 Series ; AMD Ryzen 8000 Series ; AMD Ryzen 9000 Series
CPU Socket Standard	Socket AM5
CPU Maximum Quantity Supports	1
Memory Type	DDR5 SDRAM
Memory Form Factor	DIMM 288-pin
Memory Speed	4400MHz ; 4800MHz(PC5-38400) ; 5200MHz(PC5-41600)
Maximum Installable System Memory Storage Capacity	256 GB
Memory Slot Total Quantity	4
Provides Error Checking Method	non-ECC
Memory Features	Two DDR Channels ; Unbuffered ; Dual Rank ; Single Rank ; XMP ; AMD EXPO
Plug-in-card	Wi-Fi Controller:;
Integrated	Storage Controller:; Supports: Level 0, Level 1, Level 10, Level 5; PCI Express 5.0 x4 (3 x M.2 (Key M)); Storage Controller:; Supports: Level 0, Level 1, Level 10, Level 5; PCI Express 4.0 x4 (1 x M.2 (Key M)); Storage Controller:; Supports: Level 0, Level 1, Level 10; SATA III-600 (4);
Video Controller Integrated	yes
Audio Integrated	yes
Device Location	Integrated
Audio Chipset	Realtek ALC1220
Audio Output Mode	7.1 Channel Surround
Compliant Audio Standards	High Definition Audio
LAN Integrated	yes
Wi-Fi	IEEE 802.11be Wi-Fi 7
Bluetooth	Bluetooth 5.4
Data Link Protocol Supports	2.5 Gbps
PCI Express 5.0 x16	1
PCI Express 4.0 x16	1
PCI Express 3.0 x16	1
USB 2.0	4 (USB 2.0 (type A))
USB 3.2 Gen 1	4 (USB 3.2 (type A))
HDMI	1 (HDMI (Type A))
USB 4.0	2 (USB 4.0 (type C))
LAN	1 (RJ-45)
USB 3.2 Gen 2	2 (USB 3.2 (type A))
Antenna	2
Audio Interface	2 (3.5-mm minijack)
S/PDIF-out Optical	1
BIOS Type	AMI
BIOS Features	Gigabyte Q-Flash ; WfM 2.0 Support ; PnP 1.0a Support ; UEFI ; SMBIOS 2.7 Support ; DMI 2.7 Support ; ACPI 5.0 Support
Hardware Monitoring	CPU Temperature ; CPU Voltage ; System Temperature ; System Voltage
Power Connectors Type	24+8 pin
Mainboard Features	Fan Speed Control
Software Included	Norton Internet Security (OEM version)
Supported Operating System	Microsoft Windows 11 64-bit
Form Factor	ATX
Height (mm)	244 mm
Width (mm)	305 mm
Warranty Products Returnable	Yes
Warranty Term (month)	36 months
Warranty Validation Criteria	Serial Number
Pack Weight Brutto (kg)	1.5 kg
Pack Weight Netto (kg)	1.2 kg
Pieces in pack	1
Box Weight Brutto (kg)	7.5 kg
Retail Packaging Net Weight Carton	0.2 kg
Retail Packaging Net Weight Plastic	0.1 kg
Packs in Box	5
Package Type	Retail
EAN Code	4719331864613
