MSI MAG B850 TOMAHAWK MAX WIFI, Socket AM5, 4x DDR5, WiFi7

MSI MAG B850 TOMAHAWK MAX WIFI, Socket AM5, 4x DDR5, WiFi7

Brand: MSI

MSI MAG B850 TOMAHAWK MAX WIFI, Socket AM5, 4x DDR5, WiFi7

€299.90
Tax included
Quantity
Oops this product is currently out of stock! If you want us to double check availability, please email us at: info@respawnshop.com

Reference: MAG B850 TOMAHAWK MAX WIFI
Category: Motherboards

MSI MAG B850 TOMAHAWK MAX WIFI, Socket AM5, 4x DDR5, WiFi7

Technical specifications

ChipsetAMD B850
Supports Central Processor UnitAMD Ryzen 7000 Series ; AMD Ryzen 8000 Series ; AMD Ryzen 9000 Series
CPU Socket StandardSocket AM5
CPU Maximum Quantity Supports1
Memory TypeDDR5 SDRAM
Memory Form FactorDIMM 288-pin
Memory Speed4800MHz(PC5-38400) ; 5600MHz(PC5-44800) ; 6400MHz(PC5-51200) ; 8400MHz
Maximum Installable System Memory Storage Capacity256 GB
Memory Slot Total Quantity4
Provides Error Checking MethodNon-ECC
Memory FeaturesTwo DDR Channels ; Unbuffered ; Dual Rank ; Single Rank ; XMP ; AMD EXPO
IntegratedStorage Controller:; Supports: Level 0, Level 1, Level 10; PCI Express 5.0 x4 (2 x M.2); Storage Controller:; Supports: Level 0, Level 1, Level 10; PCI Express 4.0 x4 (1 x M.2); Storage Controller:; SATA III-600 (4); Storage Controller:; Supports: Level 0, Level 1, Level 10; PCI Express 4.0 x2 (1 x M.2);
Plug-in-cardWi-Fi Controller:; 1 x M.2 (Key E);
Audio Integratedyes
Device LocationIntegrated
Audio ChipsetRealtek ALC4080
Audio Data Width32-bit
Audio Output Mode7.1 Channel Surround
Compliant Audio StandardsHigh Definition Audio ; Audio Boost 5
LAN Integratedyes
LAN ChipsetRealtek RTL8126VB
WLANM.2
Wi-FiIEEE 802.11be Wi-Fi 7; 2.4/5/6GHz
BluetoothBluetooth 5.4
Data Link Protocol Supports5 Gbps
PCI Express 5.0 x161
PCI Express 4.0 x161
PCI Express 3.0 x11
USB 3.2 Gen 22 (USB Type-A); 3 (USB Type C)
USB 3.2 Gen 11 (USB Type-A)
USB 2.04 (USB Type-A)
HDMI1 (HDMI (Type A))
Wi-Fi Antenna2
LAN1 (RJ-45)
Audio Interface2 (3.5-mm minijack)
S/PDIF-out Optical1 (TOSLINK)
BIOS FeaturesMSI CLICK BIOS X
Power Connectors Type2x8 pin
Mainboard FeaturesFan Speed Control; RGB Mystic Light
Software IncludedMSI Center
Supported Operating SystemMicrosoft Windows 11 64-bit
Cable Included1 x SATA 6Gb/s cable ; 1 to 3 EZ Conn-Cable (v2) ; EZ Front Panel Cable
Built-in DevicesClear CMOS Button
Included AccessoriesQuick Start Guide ; Documentation ; WiFi antenna ; Sticker ; M.2 Clip II Remover ; M.2 Clip II
Form FactorATX
Height (mm)243.84 mm
Width (mm)304.8 mm
Warranty Products ReturnableYes
Warranty Term (month)24 months
Warranty Validation CriteriaSerial Number
Pack Length (mm)342 mm
Pack Width (mm)268 mm
Pack Height (mm)70 mm
Pack Weight Brutto (kg)2.07 kg
Pack Weight Netto (kg)1.787 kg
Pieces in pack1
Box Weight Brutto (kg)2.07 kg
Packs in Box1
Package TypeRetail
EAN Code4711377290623
MSI
MAG B850 TOMAHAWK MAX WIFI

Specific References

EAN13
4711377290623
