GIGABYTE MB AM4 A520 2 x DDR4 PCIe 3.0 1 x M.2 4 x SATA 1 x D-Sub port 1 x DVI-D port 1 x HDMI port Micro ATX

GIGABYTE MB AM4 A520 2 x DDR4 PCIe 3.0 1 x M.2 4 x SATA 1 x D-Sub port 1 x DVI-D port 1 x HDMI port Micro ATX

Brand: Gigabyte

GIGABYTE MB AM4 A520 2 x DDR4 PCIe 3.0 1 x M.2 4 x SATA 1 x D-Sub port 1 x DVI-D port 1 x HDMI port Micro ATX

€69.90
Tax included
Quantity
Oops this product is currently out of stock! If you want us to double check availability, please email us at: info@respawnshop.com

Reference: A520M S2H
Category: Motherboards

GIGABYTE MB AM4 A520 2 x DDR4 PCIe 3.0 1 x M.2 4 x SATA 1 x D-Sub port 1 x DVI-D port 1 x HDMI port Micro ATX

Technical specifications

ChipsetAMD A520
Supports Central Processor UnitAMD Ryzen Series 4th Generation ; AMD Ryzen Series 5th Generation
CPU Socket StandardSocket AM4
CPU Maximum Quantity Supports1
Memory TypeDDR4 SDRAM
Memory Form FactorDIMM 288-pin
Memory Speed2133MHz(PC4-17000) ; 2400MHz(PC4-19200) ; 2667MHz(PC4-21300) ; 2933MHz(PC4-23400) ; 3200MHz(PC4-25600)
Maximum Installable System Memory Storage Capacity64 GB
Memory Slot Total Quantity2
Provides Error Checking MethodECC/non-ECC
Memory FeaturesTwo DDR Channels ; Unbuffered ; Dual Rank ; Single Rank ; XMP
IntegratedStorage Controller:; Supports: Level 0, Level 1, Level 10; SATA III-600 (4); Storage Controller:; PCIe 3.0 x4/SATA (1 x M.2 (Key M));
Audio Integratedyes
Device LocationIntegrated
Audio Output Mode7.1 Channel Surround
Compliant Audio StandardsHigh Definition Audio
LAN Integratedyes
LAN ChipsetRealtek RTL8118
Data Link Protocol SupportsGigabit Ethernet/Fast Ethernet/Ethernet
PCI Express 3.0 x161
PCI Express 3.0 x12
PS/21
VGA1 (15-pin D-sub)
DVI1 (DVI-D)
HDMI1 (HDMI (Type A))
USB 3.2 Gen 14 (USB 3.2 (type A))
USB 2.02 (USB 2.0 (type A))
LAN1 (RJ-45)
Audio Interface3 (3.5-mm minijack)
BIOS TypeAMI
BIOS FeaturesGigabyte Q-Flash ; WfM 2.0 Support ; PnP 1.0a Support ; UEFI ; SMBIOS 2.7 Support ; 128 Mb Flash ROM ; DMI 2.7 Support ; ACPI 5.0 Support
Hardware MonitoringCPU Temperature ; CPU Voltage ; System Temperature ; System Voltage
Power Connectors Type24+8 pin
Software IncludedNorton Internet Security (OEM version)
Supported Operating SystemMicrosoft Windows 10 64-bit ; Microsoft Windows 11 64-bit
Form FactorMicro ATX
Height (mm)205 mm
Width (mm)244 mm
Warranty Products ReturnableYes
Warranty Term (month)36 months
Warranty Validation CriteriaSerial Number
Pack Weight Brutto (kg)0.74 kg
Pack Weight Netto (kg)0.652 kg
Pieces in pack1
Box Weight Brutto (kg)0.65 kg
Retail Packaging Net Weight Carton0.01 kg
Retail Packaging Net Weight Plastic0.01 kg
Packs in Box1
Package TypeRetail
EAN Code4719331809720
A520M S2H

Specific References

EAN13
4719331809720
